NovaStar, MB251, Mattress Faux Tape Edge Sewing Machine, Nonwoven Size 100 to 200mm, 6 m/min, 1 Phase 220V (New)

NovaStar, MB251, Mattress Faux Tape Edge Sewing Machine, Nonwoven Size 100 to 200mm, 6 m/min, 1 Phase 220V

Description

  1. Overview
    1. Japan's high speed chain stitch sewing head
    2. Cover with a fixture on the edge of the wrap
    3. Auto stop for material depletion
    4. Automatic roll device
    5. Sewing head with automatic lubrication
    6. Synchronous feeding device
  2. Technical Parameters
    1. Nonwoven size: 100 to 200 mm
    2. Sewing speed: 6 m/min
    3. Border width: 100 to 400 mm
    4. Tape width: 35, 38, 40, 42, 45 mm
    5. Stitch: 2 to 5 mm
    6. Air pressure: 0.6 to 0.7 MPa
    7. Power: 0.95 kW
    8. Power supply: 1 phase 220 V, 60 Hz
  3. Dimensions and Weight
    1. Overall size: 4050 mm x 1500 mm x 1680 mm
    2. Weight: 300 kg
    3. Net weight: 350 lbs
