Singer, 300U, Fixed Table Tape Edge Sewing Machine, 1600x2000mm Table, Singer 300U Chain Stitch Head (New)

Singer, 300U, Fixed Table Tape Edge Sewing Machine, 1600x2000mm Table, Singer 300U Chain Stitch Head

Description

  1. Overview
    1. Automatic corner slow down
    2. Sewing head: Singer 300U chain stitch
    3. Sewing head lifting range: 0 to 200 mm
    4. Working angle of the sewing head: 35 to 55 degrees
  2. Specifications
    1. Work table size: 1600 mm x 2000 mm
    2. Sewing head motor rotary speed: max. 3065 rpm
    3. Max. mattress thickness: 50 to 500 mm
    4. Carriage speed: max. 13.6 meters per minute
    5. Carriage clutching mode: electromagnet clutch
    6. Productivity: 10 to 20 pieces per hour
    7. Total power: 1.65 kW
    8. Machine weight: approx. 900 kgs
  3. Additional Information
    1. More information is available upon request.
